Diaphragm

This material is available in Neoprene with a Polyester or Nylon fabric; or EPDM with a Nylon fabric. They can come with a 1 or 2 ply insertion. Diaphragm materials are suitable in applications requiring minimal oil resistance and where hot and/or cold water and gases are being transferred. Applications may include meters, control devices, regulators and pumps.

Service Limits



Polymer

Neoprene or EPDM

ASTM Designation

N/A

Colour

60-70

Durometer

Black

Temperature Range

-20°F to +180°F

Elongation

N/A

Tensile Strength

890-1400 PSI

Finish

Plate

Widths

36", 48" in 1 Ply + 2 Ply

Thickness

1/16”, 1/8”, 3/16”, 1/4”

Pressure Sensitive Adhesive (PSA)

Contact us for details

Grades

Commercial

Available Forms

Rolls





Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
