Nitrile Gaskets (NBR/Buna-N)
Nitrile (Buna N) is a synthetic copolymer of acrylonitrile and butadiene. This gasket material is highly resistant to petroleum oils, mineral oils, vegetable oils and many acids. It also has a high resistance to a broad range of aromatic hydrocarbons. Its applications range mostly in tough industrial environments. White Nitrile Buna-N is FDA approved as a food grade gasket material.
|
Service Limits |
|
|
Polymer |
Nitrile (NBR) (Buna N) |
|
ASTM Designation |
NBR |
|
Colour |
Black, White |
|
Durometer |
40, 50, 60, 70 |
|
Temperature Range |
-40°F to +200°F |
|
Elongation |
350% |
|
Tensile Strength |
1000 PSI |
|
Finish |
Smooth |
|
Widths |
36", 48" |
|
Thickness |
1/32", 1/16", 3/32", 1/8", 3/16", 1/4", 3/8", 1/2", 5/8" |
|
Pressure Sensitive Adhesive (PSA) |
Available upon request |
|
Grades |
Commercial, FDA, Industrial, Premium |
|
Available Forms |
Rolls, Sheet, Stripping, Cut gaskets, Extrusion, Molded parts |
Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
