CI Rubber & Packing

Cloth Inserted Rubber that has been reinforced with one or more plies of cloth such as polyester, nylon, cotton or fiberglass fabric. This gives added stability in flanged gasket applications requiring mechanical fastening and reduces creep when there are high compression loads.  The most common CI Rubber gasket material available is C.I Packing – SBR.  This is an SBR elastomer with an poly fabric insert. It is available in a 1 ply or 2 ply fabric. Cloth inserted SBR is suitable for use in hydraulics and where air, water or low-pressure steam is used.

Service Limits



Polymer

Styrene-Butadiene reinforced with poly fabric

ASTM Designation

N/A

Colour

Black

Durometer

60-80

Temperature Range

-20°F to +170°F

Elongation

N/A

Tensile Strength

500 PSI

Finish

Plate

Widths

48"

Thickness

1/16”, 1/8”, 3/16”, 1/4”

Pressure Sensitive Adhesive (PSA)

Available upon request

Grades

Commercial Black SBR Rubber

Available Forms

Rolls



Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
