Gylon 3545
Gylon 3545 is highly compressible; suitable for flanges and applications where a rigid gasket is required such as hard to reach piping systems. Conforms to FDA standards.
|
Service Limits |
|
|
Filler |
Microcellular PTFE & Rigid PTFE core |
|
Colour |
White |
|
Temperature range |
-450°F to 500°F |
|
Thickness |
1/16", 1/8" |
|
Sizes |
60" x 60" |
|
Maximum pressure |
1200 PSI |
|
Resistant to: |
Strong caustics, strong acids, hydrocarbons, chlorine, cryogenics, glass-lined-equipment, low bolt load applications |
|
Availability: Forms |
Sheet, Cut gaskets |
Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
