Neoprene Gaskets

Neoprene is a family of synthetic rubbers produced by polymerization of chloroprene. Neoprene gaskets resist ozone, sunlight, oxidation and many petroleum derivatives. This gasket material provides a good resistance to weather, combustion, water and many chemicals.



Service Limits

Polymer

Chloroprene Rubber

ASTM Designation

CR

Colour

Black

Durometer

40, 50, 60, 70, 80

Temperature Range

-20°F to +180°F

Elongation

350-400%

Tensile Strength

950 PSI

Finish

Plate

Widths

36", 48", 72"

Thickness

1/32”, 1/16”, 3/32”, 1/8”, 3/16”, 1/4”, 1/2”, 5/8”, 3/4”, 7/8", 1”,

Pressure Sensitive Adhesive (PSA)

Available upon request

Grades

Commercial, Flame Retardant

Available Forms

Rolls, Sheet, Slab, Stripping, Cut gaskets, Extruded parts, Molded parts



Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
