Novatec 825

Novatec 825 is highly compressible and conformable, with moderate density. It has a high resistance to temperature, and it becomes a perfect solution for elevated temperature applications and poor or irregular flange surfaces. This gasket material has a non-stick easy-release coating and is ideal for less than perfect flanges with 45% compressibility.

Service Limits

Fibers

Graphite with Kevlar®

Binder

Nitrile (NBR)

Colour

Cranberry

Temperature range

Max: +825°F,                                       Continuous max: +347°F

Thickness

1/32", 1/16", 1/8", 3/16"

Sizes

59" x 59"

Maximum pressure

1500 PSI

Resistant to:

High adaptability & high temperature

Applications

Valve covers in diesel engines



Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
