Santoprene

Santoprene isn’t a rubber, it isn’t a plastic; its both. Santoprene consists of thermoplastic elastomer vulcanized rubber particles dispersed throughout a heat-formable plastic base. It is an NSF-61 certified material. It has high resistance to compression set after repeated deflection. It is excellent at particularly high temperatures and for long periods of time. Santoprene is well-suited for potable water, water treatment, and many applications requiring especially tight sealing. Santoprene can be thermally welded.

Service Limits

Type

Value

Polymer

Thermoplastic Vulcanizate & Elastomer

ASTM Designation

TPV/TPE

Colour

Neutral

Durometer

55, 60, 80

Temperature Range

-81°F to +275°F

Elongation

330%

Tensile Strength

640 PSI

Finish

Matte (others available)

Widths

36"

Thickness

1/8",1/4"

Pressure Sensitive Adhesive (PSA)

Available upon request

Grades

FDA, NSF-61,

Available Forms

Extrusions



Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
