Santoprene
Santoprene isn’t a rubber, it isn’t a plastic; its both. Santoprene consists of thermoplastic elastomer vulcanized rubber particles dispersed throughout a heat-formable plastic base. It is an NSF-61 certified material. It has high resistance to compression set after repeated deflection. It is excellent at particularly high temperatures and for long periods of time. Santoprene is well-suited for potable water, water treatment, and many applications requiring especially tight sealing. Santoprene can be thermally welded.
Service Limits |
|
Type |
Value |
Polymer |
Thermoplastic Vulcanizate & Elastomer |
ASTM Designation |
TPV/TPE |
Colour |
Neutral |
Durometer |
55, 60, 80 |
Temperature Range |
-81°F to +275°F |
Elongation |
330% |
Tensile Strength |
640 PSI |
Finish |
Matte (others available) |
Widths |
36" |
Thickness |
1/8",1/4" |
Pressure Sensitive Adhesive (PSA) |
Available upon request |
Grades |
FDA, NSF-61, |
Available Forms |
Extrusions |
Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
