Viton Gaskets (FKM)
FKM elastomer is more commonly known by its two trade names: VITON (E.I Dupont) & FLUOREL (3M Co.). The generic term for this gasket material is Fluoroelastomer. It is a high performance synthetic rubber, offering unique resistance to heat, aggressive chemicals, and compression set.
|
Service Limits |
|
|
Type |
Value |
|
Polymer |
Fluoroelastomer |
|
ASTM Designation |
FKM/FPM |
|
Colour |
Black, White, Brown |
|
Durometer |
60-70 |
|
Temperature Range |
-10°F to 450°F |
|
Elongation |
300% |
|
Tensile Strength |
500-2000 PSI |
|
Finish |
Fabric, Smooth |
|
Widths |
36", 48” |
|
Thickness |
1/32", 1/16", 3/32", 1/8", 3/16", 1/4" |
|
Pressure Sensitive Adhesive (PSA) |
Available upon request |
|
Grades |
Premium, Industrial, commercial, Viton A, Viton B, Viton F, Viton GF, Viton GFLT |
|
Available Forms |
Rolls, Sheets, Stripping, Cut gaskets, Extrusion, Molded gaskets |
Disclaimer: The above values are typical properties and are provided for information only. They should not be used to set specification requirements. It is up to the end user to determine whether the material is suitable for the intended application.
